線性磨耗儀的應用對象：
能測試任何尺寸大小或任何形狀的樣品，對于帶輪廓表面和拋光表面特性產品的磨耗測試極為理想(如：電腦鼠標和其它電腦或IT產品塑膠面漆耐磨性測試)，通用于塑料、汽車配件、橡膠、皮革和紡織、電鍍、自由拆卸的組件、漆品、印刷圖樣等產品。
Application object of linear abrasion tester:
It can test samples of any size or shape. It is ideal for the wear test of products with contour surface and polished surface characteristics (such as the wear resistance test of plastic finish paint of computer mouse and other computer or it products). It is widely used in plastics, auto parts, rubber, leather, textile, electroplating, freely removable components, paints, printing patterns and other products.
線性磨耗儀符合標準：
Linear abrasion tester meets the standard:
ASTM D3884 、 ASTM D1175 、 ASTM D1044 、 ASTM D4060 、 TAPPI T476 、 ISO 9352 、 ISO 5470-1 、 JIS K7204 、 JIS A1453 、 JIS K6902 、 JIS L1096 、 JIS K6964 、 DIN 52347 、 DIN 53109 、 DIN 53754 、 DIN 53799 等多種標準。
線性磨耗儀特征：
(1). 模擬真實的使用條件：
-可設置移動距離、轉速、轉數、載重等參數
-可選擇多種不同的磨耗介質和配件。
(可選的樣品固定臺及其他可選配件，配合進行刮傷、破損程度測定以及耐酒精測試、耐硬幣刮擦等的測定)
(2).確保測試的穩定性和準確性：
一般磨頭其大小、形狀如同鉛筆末端的橡皮擦頭，是用高質量的磨耗材質制作而成。能確保測試的穩定性
激光導引測試樣品的擺放位置，確保測試的準確性。
Linear abrader features:
(1). Simulate real service conditions:
-Parameters such as moving distance, rotating speed, revolutions and load can be set
-A variety of different wear media and accessories can be selected.
(optional sample fixing table and other optional accessories can be used to determine the scratch and damage degree, alcohol resistance test, coin scratch resistance, etc.)
(2). Ensure the stability and accuracy of the test:
Generally, the size and shape of the grinding head are like the eraser head at the end of a pencil. It is made of high-quality wear materials. It can ensure the stability of the test
The laser guides the placement of test samples to ensure the accuracy of the test.
線性磨耗儀的功能介紹：
. 用于評估產品的耐磨性、耐刮擦性(單次或多次刮擦)和顏色的傳遞性（通常是耐磨擦脫色或耐磨擦牢度）等等。
2). 干磨耗測試、濕磨耗測試均可進行。
3). 磨損儀包括LAT主機，3個250g圓盤形砝碼等。
4). 磨損儀有5種可選的移動距離
· 標準移動距離 0.5", 1", 2" 3" 和 4"
· 可訂做特殊的移動距離
· 10～100來回/分鐘的可調移動速度
· 可設置轉數
· 可最多設置 400萬 轉（注意，磨頭橡皮在此期間可能需要更換）
· 可選擇載重
· 標準載重范圍從350g到2100g ( 一般隨機配置250g重量的砝碼3個）。
· 各種可選的重量的砝碼。
設備外形尺寸：550*250*230mm(帶右側平臺)、430*250*230mm(不帶右側平臺)
設備重量：40KG(帶右側平臺)、35(不帶右側平臺)
電源：220V 50Hz
Function introduction of linear wear meter:
It is used to evaluate the wear resistance, scratch resistance (single or multiple scratches) and color transmissibility of products (usually abrasion decolorization or abrasion fastness), etc.
2). Dry abrasion test and wet abrasion test can be carried out.
3). The wear tester includes lat host, three 250g disc-shaped weights, etc.
4). The wear gauge has five optional travel distances
·Standard travel distance 0.5 ", 1", 2 "3" and 4 "
·Special moving distance can be customized
·Adjustable movement speed of 10 ~ 100 round trips / min
·The number of revolutions can be set
·Up to 4 million revolutions can be set (note that the grinding head rubber may need to be replaced during this period)
·Optional load
·The standard load range is from 350g to 2100g (generally, three 250g weights are randomly configured).
·Various optional weights.
Overall dimensions of equipment: 550 * 250 * 230mm (with right platform), 430 * 250 * 230mm (without right platform)
Equipment weight: 40kg (with right platform), 35 (without right platform)
Power supply: 220V 50Hz
標準配置：
包括線性磨耗主機，3個250G圓盤形砝碼，2個橡皮磨頭。
Standard configuration:
Including linear wear host, 3 250g disc weights and 2 rubber grinding heads.
注1）詳細參數：
①5種可選的移動距離：0.5”,1”,2”,3”和4”;可訂做特殊的移動距離。
②可設置轉數。可最多設置400萬轉（注意，磨頭橡皮在此期間可能需要更換）。
③10~100來回/分鐘的可調移動速度。
④可選擇載重。標準載重范圍從350G到2100G（一般隨機配置250G重量的砝碼3個）。亦可訂做各種重量的砝碼。
Note 1) detailed parameters:
① 5 optional moving distances: 0.5 ", 1", 2 ", 3" and 4 "; Special moving distance can be customized.
② The number of revolutions can be set. Up to 4 million revolutions can be set (note that the grinding head rubber may need to be replaced during this period).
③ Adjustable movement speed of 10 ~ 100 round trips / min.
④ Optional load. The standard load range is from 350g to 2100g (generally, three 250g weights are randomly configured). Weights of various weights can also be customized.
